Product Details

D03S Thermal Transfer Overprinter

S Series TTO is world class cost effective smart coding machine, mainly used in flexible package area like food, pharmaceutical, dalit chemical, seed, daily tissue, etc.

Product case

Installation

Sample-1

Sample-2

Product features

Unique design

Using motor collaborative precision control, the printing gap is accurate up to 0.1mm

Print speeds range from as low as 20mm/s

Maximum speed up to 670mm/s

Efficient

Add a variety of ribbon saving functions to improve ribbon utilization

Adapts to automatic blanking lines to avoid missing and drifting in the print position

Add network interface to facilitate system communication applications

Efficient intelligent

Enhance your brand: 300DPI resolution, ensures superior print apperance and makes your products out of the ordinaries. Enhance your efficiency: print real time, date and lot numver, work file can be changed easily; max 600 ribbon length, reeduce machine downtime; friendly UI and operation; easy to learn designer program. Reduce TCO.

Protect your property: adopts 32mm &53mm print head, suitable for 22-55mm ribbon width, deploy property to meet different applications; minimum 0.1mm print gap; distinct good adhension on the film, avoid unexpected complains. Reduce cost.

Protect your chnnels: print variable QR Code, barcode with our self designed system to fulfill tracing and tracebility anti-counterfeit, protect your channels.

Machine dimension drawing

Product parameters

Print Model	Intermittent		Continuous
Print Head	32mm width，300DPI
Print Area	32mm X 60mm		32mm X 150mm
Print Speed	6-20m/min		＜ 40m/min
Frequency	＜ 200 times/min	＜ 200 times/min
Ribbon	22mm -33mm*500m
Interface	USB、Ethernet、RS232
Electricity	AC100 ～ 240 V， 50/60Hz
Power	200W
Working Temp	0~40℃
Relative Humidty	10％~95％（no-condensing）
Air Supply	0.6Mpa （max)，dry，non-polluted air
Weight	Print unit: 8.5kg，Controller: 2.0kg
Dimension（LxWxH）	Print unit: 190mm×192mm×180mm, Controller: 233mm×180mm×155mm

Consumables

Model	Grade	Features
DG	wax/resin	cost effective to meet most printing requirements
DC	permium wax/resin	better adhension, cost effective
DT	resin	superior adhension for high quality prints
DCLL	combined	better adhension, cost effective
